Goodman 3 Ton 14.3 SEER2 Air Conditioner Coil System 17.5"W Horizontal R32
Key Features
- Efficiency: Rated at 14.3 SEER2 for energy-efficient performance
- Capacity: Delivers 36,000 BTU/h as a complete matched system
- Refrigerant: Factory-charged with R32 refrigerant for reliable, eco-conscious operation
- Performance: Scroll compressor ensures quiet, consistent, and energy-efficient operation
Seer Rating: 14.3 SEER2
Tonnage: 3 Ton
Product Details
Product Details
Goodman 3 Ton 14.3 SEER2 Air Conditioner Coil System 17.5"W Horizontal R32
Goodman 3 Ton R32 Split Air Conditioner 15.2 SEER2 Single Stage GLXS5BA3610
The Goodman 3 Ton (36,000 BTU) R32 Split Air Conditioner (Model GLXS5BA3610) delivers superior efficiency with a 15.2 SEER2 rating and a high-performance single-stage scroll compressor. It uses R-32 refrigerant and is factory pre-charged for 15' tubing length, simplifying installation. Features include 5mm copper tubing with enhanced aluminum fin coils for excellent heat transfer, sweat connection service valves for easy maintenance, and extended-life capacitors for long-lasting performance. The robust cabinet is corrosion-resistant, with a Venturi design for improved airflow, while the unit is AHRI certified and ETL listed. Designed for durability, it meets 2023 Florida Building Code integrity requirements for hurricane readiness and offers easy access for servicing.
- Refrigerant Type: R-32
- Unit Height: 39.5 in
- Unit Width: 35.5 in
- Communication Feature Type: Non-Communicating
- Max Overcurrent Protection: 30 A
- Power Phase: 1 Ph
- Power Voltage: 208/230 V
- Compressor Stages: Single Stage
- Compressor Type: Scroll
- Tonnage: 3
- 36,000 BTU
- Model Efficiency: 15.2 SEER2
Key Features
- Efficiency: Rated at 14.3 SEER2 for energy-efficient performance
- Capacity: Delivers 36,000 BTU/h as a complete matched system
- Refrigerant: Factory-charged with R32 refrigerant for reliable, eco-conscious operation
- Performance: Scroll compressor ensures quiet, consistent, and energy-efficient operation
Cabinet Features
- Removable grille-style top compliant with UL 60335-2-40 for safety and easy maintenance.
- Venturi design enhances airflow velocity for improved performance.
- Architectural gray powder-paint finish offers corrosion resistance with 500-hour salt-spray approval.
- Wire fan discharge grille protects internal components while maintaining airflow efficiency.
- Steel louver coil guard provides robust protection for the coils.
- Top and side maintenance access for convenient servicing.
- Single-panel access to controls with space for field-installed accessories.
- Hurricane-ready design meets 2023 Florida Building Code integrity requirements when properly anchored (anchor bracket kits available).
Goodman 3 Ton R32 Cased Evaporator Coil Horizontal with Internal TXV 17"W CHPTA3630B3
The Goodman 3 Ton R32 Cased Evaporator Coil (CHPTA3630B3) is a durable, efficient horizontal coil featuring an all-aluminum design optimized for R-32 refrigerant. With factory-installed TXV valves, it supports both cooling and heat pump systems for enhanced energy performance. Compact at 21" depth and 17.5" height, it fits tight spaces and includes a front access panel for easy servicing. Rust-resistant thermoplastic and UV-resistant drain pan, foil-faced insulation, and galvanized finish ensure longevity. AHRI and ETL certified for quality and safety compliance.
- Refrigerant Type: R-32
- Unit Height: 17.5 in
- Unit Width: 30 in
- Cased/Uncased: Cased
- Coil Application: Horizontal A
- Unit Depth: 21 in
Key Features
- Efficiency: Rated at 14.3 SEER2 for energy-efficient performance
- Capacity: Delivers 36,000 BTU/h as a complete matched system
- Refrigerant: Factory-charged with R32 refrigerant for reliable, eco-conscious operation
- Performance: Scroll compressor ensures quiet, consistent, and energy-efficient operation
