Goodman 5 Ton Evaporator Coil EEV Expansion 24.5" Cabinet Upflow/Downflow

By: Goodman
SKU: CAPEA6030D3|ID: 101274
$1,008.00
+ Free shipping
Width: 24.5"
Depth: 21"

Key Features

  • Capacity: Delivers 60,000 BTU/h as a complete matched system
  • Refrigerant: Factory-charged with R32 refrigerant for reliable, eco-conscious operation
  • Certifications: AHRI Certified and ETL Listed for verified safety and performance standards
  • Installation: Designed for easy installation as a matched system with compatible Goodman components

Cabinet Width: 24.5"

17.5"21"24.5"

Configuration: Vertical

Vertical

Tonnage: 5 Ton

3 Ton4 Ton5 Ton
Working on a big project?
Free Shipping On Orders $1000 See our shipping policy
Flexible Financing Finance with Affirm. See terms
Speak with an Expert Call us at (888)-868-1055

Product Details

Goodman 5 Ton Evaporator Coil EEV Expansion 24.5" Cabinet Upflow/Downflow

Goodman 5 Ton Evaporator Coil EEV Expansion 24.5" Cabinet Upflow/Downflow CAPEA6030D3

The Goodman CAPEA6030D3 is a 5-ton evaporator coil designed specifically for horizontal applications in split system air conditioners and heat pumps. Engineered with an all-aluminum A coil, this unit ensures long-lasting durability and efficient heat transfer. It comes factory-equipped with a thermal expansion valve (TXV) to provide accurate refrigerant control for R-32 systems. Additional features include foil-faced cabinet insulation to manage condensation and a DecaBDE-free thermoplastic drain pan for added environmental compliance. Ideal for residential installations between 2,400 and 3,000 square feet, this coil supports both cooling and heating operations.

Key Features

  • Capacity: Delivers 60,000 BTU/h as a complete matched system
  • Refrigerant: Factory-charged with R32 refrigerant for reliable, eco-conscious operation
  • Certifications: AHRI Certified and ETL Listed for verified safety and performance standards
  • Installation: Designed for easy installation as a matched system with compatible Goodman components

Designed for energy-efficient performance in cooling and heat pump systems, this horizontal evaporator coil is a reliable choice for modern HVAC applications requiring R-32 refrigerant compatibility.

Learning Resources

CAPEA Installation Manual CAPEA Specifications Sheet CAPEA Warranty Information

Specifications

BrandGoodman
SKUCAPEA6030D3
Product TypeEvaporator Coil
ConfigurationHorizontal
Cooling Capacity5.0 Ton
Cooling BTU60000 BTU
Refrigerant TypeR32
TXV InstalledYes
CasingCased
Coil TypeA Coil
Cabinet Width24.5 inches
Product Width30 inches
Product Height24.5 inches
Product Depth21 inches
Suction Connection Size7/8 inch
Liquid Connection Size3/8 inch
CertificationsAHRI, ETL, ISO
Product Weight67 pounds
Parts Warranty10 Limited Years

Warranty and Product Information

Standard Warranty5 years
Registered Warranty10 years
